SMALL TYPE 2

    Dimensions: 1.5 x 2 meter
    Total weight: 210 kg

    The bracing box is reversible i.e. it can be flipped and used at 1,5 or 2 meter depth, depending on how you place the spindles.

    Available with spindles 60-80 cm, 80-121 cm and 129-218 cm. Read more about the spindles and find the dimensions of the work width of the box under accessories. The working height under the spindles is 75-80 cm.

    Small Bracing box Type 2 is ideal when you need to perform tasks in limited space or in hard-to-reach areas.

    Small Type 2
    Goals:1.5 x 2,0 m
    Weight per page:90 kg
    Total weight:210 kg
    Pressure:17 kn/m2



    SpindlerInteriorExterior
    60 – 8148 – 6957 – 78
    80 – 12168 – 10977 – 118
    129 – 218117 – 206126 – 215

    All measurements in cm

    Developed according to EN 13331-1 + CE approved metal frame
