Measure: 1,5 x 2 m
Total Weight: 300 kg
Stengers Small Trench Boxes can be flipped 90, 180 or 270 degrees making it reach 1,5 or 2 meter depth.
Comes with standard struts 60-80 cm, 80-121 cm og 129-218 cm. Additional lengths are possible – please contact us for further information.
Our boxes size and strength to weight ratio combined with the versatility, makes them the perfect match with even very small excavators, working in cramped worksites or areas with poor accessibility.
| Small Type 3 | ||
| Measures: | 1,5 x 2,0 m | |
| Weight per side: | 135 kg | |
| Total weight: | 300 kg | |
| Pressure: | 26 kn/m2 | |
| Strutss | Inside | Outside |
| 60 – 81 | 54 – 75 | 65 – 86 |
| 80 – 121 | 74 – 115 | 85 – 126 |
| 129 – 218 | 123 – 212 | 134 – 223 |
All measurements in cm.
Developed following standard EN 13331-1 and a CE approved metal frame
